Rolls-Royce Germany Finds Way to Increase a Grinding Capacity

By United Grinding

Blohm Jung in Hamburg wins contract, greatly reduces auxiliary times

United Grinding Lead 768x432.jpg
For Tim Riegelhof, the hand scanner makes things much easier. The data have scarcely been read in before the software automatically sets the workpiece-specific NC program.

Christoph Fedler, project director for equipment management at Rolls-Royce Germany, was facing a challenge: He needed to increase the available capacity of the prime discipline at the Oberursel facility, namely micrometer-precise grinding of curvic couplings.

Rolls-Royce, active in the fields of civil aviation, defense and power systems, employs roughly 10,000 employees at 11 locations in Germany. For Fedler’s field, civil aviation, the company is the largest producer of motors for large-scale airplanes, such as those from Boeing or Airbus.

Aviation is an enormous growth market for Rolls-Royce, with order books full for the coming years. Rolls-Royce thus is under pressure to boost productivity, such as through investments in new technology.

Rolls-Royce identified five primary criteria for any new grinding machine:

  • Extreme production precision.
  • Repeatability and therefore process stability. After all, the drum on which the curvic coupling is ground is itself already manufactured to high level of precision.
  • The newly acquired grinding machine would need to demonstrate high technical availability.
  • The process would need to involve a change from oil to an emulsion-based cooling agent.
  • Simplification and associated time savings in preparing workpieces through use of a customer-specific upgrade station.

Complex Project

In the first quarter of 2015, the team under Fedler gathered the specifications for the new grinding machine. Over the course of one year, Rolls-Royce evaluated several suppliers and conducted technical/technological discussions. The contract was ultimately awarded to Blohm Jung in Hamburg and its Blohm Profimat MC 610 VS.

“The Profimat is working at tolerance range a grade above that of the competition. Our experience with an existing Blohm Profimat MC also plays a very important role. It has been a reliable and precise worker for over 10 years,” Fedler said of the decision.

Another year world pass until the Blohm Profimat MC was ready for commissioning. “It was a complex project with difficult requirements and the need to make many changes during the project-management phase. The project management team at Blohm always responded quickly and presented solutions, even if they were demanding,” said Christopher Boll, director of equipment management at Rolls-Royce.

The new Blohm Profimat MC 610 VS went online shortly before the end of 2017, and it delivered positive results from the start.

50% Reduction in Auxiliary Times

For Rolls-Royce, the investment in the Blohm Profimat MC 610 VS has been more than worthwhile.

United Grinding 2.jpg
The Blohm Profimat MC 610 VS successfully used at Rolls-Royce.

“We have been able to reduce the auxiliary times by up to 50 percent,” said Michael Lange, a components planner at Rolls-Royce. “Thanks to this massive reduction, workpieces from other machines can now be handled by the new grinding machine from Blohm, as well. The new Profimat MC has not only replaced the previous machine, but further expanded the available capacity, as well. What other benefits did the machine bring? It is much easier to operate. This includes, for example, the customer-specific set-up unit. It allows the operator to begin preparing a new component outside the machine while a different workpiece is still being machined inside. The measuring probe offers an enormous boost to process safety, as it measures based on pre-defined quality parameter while grinding is still ongoing. The data is sent online to the Rolls Royce quality assurance program.

The Profimat MC is a powerful grinding centre.

This extremely compact traveling-column machine offers everything modern production solutions require, with a machine width of just 2400 mm. Different spindle variants enable diverse applications.

The five-axis CNC profile grinding machines in the series can be equipped with a horizontal spindle for drive capacities up to 60 kW, as well as a stationary or an NC-swiveling vertical spindle with grinding spindle speeds of up to 60,000 revolutions per minute.

The traveling-column machine is suitable for conventional grinding tasks and CD, IPD and all CBN methods.

Customer-Specific Adaptation

The performance of the vertical spindle was adjusted to the customer’s needs.

In order to better control the Z-axis, Blohm also installed two gantry drives. Specially for Rolls-Royce, the Profimat MC was equipped with a 0-point tensioning system with four mold cavities.

The machine’s rotary table has a diameter of 800 mm. The stainless steel working space was extended laterally for the grinding wheel changing tool, making it easier to replace the cup wheel from the working space of the machine.

Another new feature: The set-up station is also equipped with a rotary table outside the machine that is identical to the rotary table inside the machine.
The workpiece is clamped on the rotary table and fixed directly on the 0-point tensioning system using the base plate.

United Grinding 3.jpg
The measuring probe measures the defined quality parameters during grinding.

The operator can then rotate the rotary table and measure the workpiece to the desired tolerance in terms of the circular and axial run-out.

The clamped workpiece is then inserted into the machine with the base plate and the grinding process can be started.

To further enhance quality, the shape of the coolant nozzles was customized and can also move into a vertical position (C axis). This ensures the workpieces are optimally cooled.

“One particular challenge posed on Blohm Jung was the vertical dressing unit. That was no easy task for their designers,” Fedler said.

The original machine is designed to handle a grinding wheel diameter of 400 mm. Rolls-Royce, however, needed a grinding wheel diameter of up to 560 mm.

The cup wheel must be able to move into dressing, as well as replacement position. Space for all these steps within the machinery space is extremely tight.

“Our designers have really delivered a great deal of performance here,” said Ulrich Haar, project manager at Blohm Jung.

Software Interface Self Explanatory

The user interface for the Blohm software is based on Siemens 840 D solution line.

The interface, which has been specifically adapted to the needs of curvic grinding, is self explanatory and the operator can work intuitively.

“The software is modular and clear,” said Christoph Weber, team leader at Rolls-Royce. “That software is also our insurance: if the operator makes a false measurement or input, the software immediately recognizes this and gives an error message.”

He is also enthusiastic about the hand reader. It can read the barcode on each component, calling up the corresponding NC data automatically in the software so that the proper grinding parameters can be applied.

Always room to improve

With the first set of performance data already gathered from the new machine, it is time for optimization.

The grinding wheel currently requires an excessive amount of dressing, a problem that will likely be solved by installing a grinding wheel with different specifications.

Beyond this, the set-up station will also be simplified: “We’ve enjoyed the dedicated support from the Blohm team and appreciate their innovative and respectful cooperation,” Fedler said.
